Wittur Augusta Evo Lift Landing Door

Advantages:

• Affordable quality door for the residential market.
• Effective design / Reduced depth and height dimensions.
• Easy and fast installation / maintenance.

INSTALLATION

• Reduced depth and height dimensions
• 3D adjustment possibilities to overcome offset shaft and irregular field conditions
• Fast assembly time

PERFORMANCE

• Low vibrations due to assembly design
• Same rollers as Hydra series guarantee low operating noise
• Upper rollers 56Ø mm
• Integrated reclosing device
• Proven reliability and durability of key components

MAINTENANCE

• Easy access for maintenance parts
• Same components for central and side opening version
• Reduced stock and spare part management

EXECUTIONS

• Standard metal sheet panels
• Fire rated metal sheet panels
• Different frame types and sizes possible

FINISHES

• Prime finish painted (RAL 7032)
• Special RAL Powder painted
• Stainless steel
• Skinplate

Code	Drive position	Series	Door Type	Illustration	Clear opening min. (mm)	Clear opening max. (mm)	Clear height min. (mm)	Clear height max. (mm)
01/C			01/C		800	1100	2000	2200
11/L			11/L		800	1100	2000	2200
11/R			11/R		800	1100	2000	2200
